500 kg – 900 mm H (All Size Available)
Rs. 26,000
(Taxes to be paid extra)
Brand: SRE
Min Order Qty: 1
Production line transfer operations in Vadodara‘s manufacturing plants face a recurring bottleneck: moving a 200–500 kg sub-assembly or workpiece from a height-adjusted work platform onto a conveyor, roller track, or trolley at an adjacent station. Without a roller-top surface on the lift table, this transfer requires lifting the load manually or using a second piece of equipment — adding time, operator effort, and injury risk to every transfer cycle. The Scissor Lift Table With Roller in Vadodara solves this directly: a 500 kg rated hydraulic scissor lift table with an integrated roller-top platform that raises the load to the exact height of the receiving conveyor or station, then allows the operator to slide the load horizontally onto the receiving surface with minimal push force — priced at Rs. 26,000. For plant engineers and production managers across Vadodara, Pune, and Ahmedabad, this is the equipment that eliminates the “last-metre” transfer problem in production line layouts.
What Makes the Roller-Top Scissor Lift Table Different — and Which Applications Need It Specifically
The key functional difference between a standard scissor lift table and a roller-top scissor lift table is the platform surface: standard units have a flat checker plate or smooth plate surface that holds loads stationary at height; roller-top units have a bed of parallel steel or PU-coated rollers across the platform that allow loads to be pushed or pulled horizontally off the platform once it reaches the target height. This transforms the table from a purely vertical lift device into a vertical-then-horizontal transfer station. The combination is essential wherever a production line involves height-adjustment before station-to-station horizontal transfer — a configuration common in assembly lines, packaging lines, and conveyor-fed production cells across Vadodara, Pune, Noida, and Bangalore.
In pump and valve manufacturing plants in Vadodara and Ahmedabad, sub-assemblies move between machining, assembly, and test stations that are all at different heights. A roller-top scissor lift table at each station transition point replaces the manual tilting, sliding, and repositioning that previously required 2–3 operators per transfer. With the lift table: one operator pumps to height, confirms alignment, and pushes the load onto the receiving roller track. Transfer time drops from 4–6 minutes per station transition to under 60 seconds. In packaging and FMCG lines in Ahmedabad, Hyderabad, and Chennai, the roller-top table acts as a buffer accumulation point — carton loads are raised to conveyor infeed height and rolled onto the conveyor belt in a smooth, continuous flow rather than being individually lifted by operators at the conveyor edge. SRE Material Handling Equipment Pvt. Ltd., an ISO 9001:2015 certified manufacturer, builds the roller bed from 50 mm diameter steel rollers on 75 mm centres — the optimal spacing for boxes, trays, and standard pallet loads without load-sag between rollers.
Applications by Sector
- Assembly Line Transfer Points: Station-to-station sub-assembly transfer in Vadodara, Pune, and Faridabad engineering plants.
- Conveyor Infeed Stations: Raising pallet loads to conveyor belt height for smooth infeed in FMCG and pharma packaging lines in Ahmedabad and Hyderabad.
- Printing & Bindery: Feeding paper and board stacks onto printing machine feeders in Vadodara, Bhopal, and Jaipur print facilities.
- Cold Chain Logistics: Transferring carton pallets onto refrigerated conveyor systems in cold storage facilities in Gujarat and Maharashtra.
- Die & Mould Transfer: Moving dies from storage-height to press-bed height then sliding onto press bolster — an alternative to a dedicated die loader for lighter dies (below 500 kg) in Vadodara press shops.
- Maintenance Workshops: Positioning heavy components at work height then sliding onto machine tool tables in repair bays in Vadodara and Ahmedabad.
- Warehouse Order Fulfilment: Raising cases from pallet height to sorting conveyor infeed height in fulfilment centres in Gurugram, Noida, and Bangalore.
Roller Specifications That Matter for Industrial Use
The roller assembly on a scissor lift table is often the first component to fail in cheap units because undersized rollers sag under repeated heavy loads, and ungraded bearings develop flat spots within months. SRE’s roller-top scissor lift tables use 50 mm diameter steel rollers with sealed ball bearings rated at 120 kg per roller. At 75 mm roller centres, a standard 820 mm wide platform carries 10–11 rollers, giving a combined roller capacity above the platform’s 500 kg rated load with an individual-roller safety margin. The roller shaft ends are secured in machined steel end-brackets — not the thin-gauge stamped brackets common in import-grade units — ensuring rollers remain parallel under eccentric loading when a workpiece is pushed across asymmetrically.
Get Scissor Lift Tables with Roller for your production line in Vadodara — SRE’s certified quality at Rs. 26,000.
Get a Quote for Bulk Orders 📞 Call Now: +91 93162 08879Technical Specifications & Comparison: Roller-Top vs. Flat-Top Scissor Lift Table for Gujarat and Maharashtra Plants
| Feature | Roller-Top Scissor Lift Table | Flat-Top Scissor Lift Table |
|---|---|---|
| Platform Surface | Steel rollers (50 mm, 75 mm centres) | MS checker plate or smooth plate |
| Vertical Lift | Yes — hydraulic, 0 to 900 mm | Yes — hydraulic, 0 to 900 mm |
| Horizontal Load Transfer | Yes — push/pull load off platform | No — load must be manually lifted off |
| Best Application | Production line transfer stations, conveyor infeed | Assembly workstations, maintenance bays |
| Load Capacity | 500 kg | 500 kg |
| Price | Rs. 26,000 (taxes extra) | Rs. 26,000 (taxes extra) |
| Custom Roller Types | Steel or PU-coated rollers available | N/A |
SRE Material Handling Equipment Pvt. Ltd. manufactures both roller-top and flat-top scissor lift table variants across the SRE 146 platform range. The roller-top variant is the same structural unit with the roller bed installed in place of the standard platform plate — so capacity, height range, scissor geometry, and hydraulic system are identical. For applications in Vadodara, Ahmedabad, Bhavnagar, Ghandhidham, Pune, and Bangalore where both types are needed across different stations, SRE can supply mixed orders from a single purchase order. Pair with an SRE hydraulic pallet truck to load the lift table efficiently and with a hydraulic stacker for vertical storage integration.
An FMCG packaging facility in Ahmedabad with a conveyor-fed packing line had operators manually lifting 30–50 kg carton bundles from floor-level pallets onto the 800 mm high conveyor infeed. After deploying 4 SRE roller-top scissor lift tables at conveyor infeed points, pallet-to-conveyor transfers became a single-operator, zero-lift operation. Operator shoulder injury claims dropped from 5 per year to 0. Line throughput increased by 12% because transfer hesitation time was eliminated. Total investment: Rs. 1,04,000 for 4 units.
Procuring Roller-Top Scissor Lift Tables for Vadodara, Pune, and Multi-Plant Operations
For project engineers and procurement managers in Vadodara, Noida, Indore, and Jaipur specifying roller-top scissor lift tables for production line upgrade projects, the key custom specifications to confirm before ordering are: roller diameter and material (steel for heavy loads, PU-coated for sensitive products like painted parts or glass), roller spacing (75 mm standard; specify 50 mm for small-footprint loads), roller orientation (parallel to platform length or perpendicular — determines the direction of load transfer), and platform size matching the width of the smallest load to be transferred. SRE Material Handling Equipment Pvt. Ltd. — ISO 9001:2015 certified — provides technical drawings and roller specification consultation before bulk orders. Standard lead time is 12–15 working days for roller-top variants. For facilities also requiring overhead lifting, review SRE’s chain block and hoist range to complement the lift table setup.
Order Roller-Top Scissor Lift Tables for your production line transfer stations — custom roller specs available from SRE.
Request Bulk Order Quote 📞 Call: +91 97247 22404Frequently Asked Questions (FAQ)
What is the specific advantage of a Scissor Lift Table With Roller over a flat-top table for production lines in Vadodara?
A roller-top scissor lift table allows the load to be pushed horizontally off the platform once it reaches the target height — enabling a single-operator, zero-lift transfer from the table onto a conveyor, roller track, or adjacent station. A flat-top table holds the load stationary at height and requires the load to be manually lifted off. For production line transfer stations in Vadodara, Pune, and Ahmedabad where loads move station-to-station continuously, the roller-top eliminates manual lifting at every transfer point — reducing injury risk and transfer time simultaneously.
What roller specifications should I look for when buying a roller-top scissor lift table for heavy industrial loads in Gujarat?
For heavy industrial loads in Gujarat, the roller spec to verify is: minimum 50 mm roller diameter (smaller rollers deflect under heavy loads), sealed ball bearings rated at 100+ kg per roller, machined steel end-brackets (not stamped-sheet), and 75 mm or less roller centre spacing for uniform load distribution. SRE Material Handling Equipment Pvt. Ltd. uses 50 mm diameter steel rollers with sealed bearings rated at 120 kg each, on 75 mm centres — specifications that sustain rated 500 kg load without individual roller fatigue in continuous production use.
Can a roller-top scissor lift table be used as a conveyor infeed station in pharma packaging lines in Ahmedabad and Hyderabad?
Yes. The roller-top scissor lift table is commonly deployed as a conveyor infeed station in pharma packaging lines in Ahmedabad and Hyderabad — raising pallet loads of cartons or cases to conveyor belt height, then rolling them onto the conveyor infeed. For GMP pharma zones, SRE Material Handling Equipment Pvt. Ltd. supplies roller-top tables with PU-coated rollers (preventing metal particle contamination) and optional SS 304 structural frame. Standard lead time for GMP-spec variants is 15–20 working days from confirmed order.
What is the price of a Scissor Lift Table With Roller in Vadodara and how does it compare to a flat-top table?
The SRE Scissor Lift Table With Roller is priced at Rs. 26,000 (taxes extra) in Vadodara — identical price point to the flat-top variant for the 500 kg, 900 mm standard configuration. Both share the same scissor mechanism and hydraulic system; the roller bed replaces the flat plate. The roller-top delivers additional horizontal transfer functionality at no additional cost. For applications that need both flat-top (for assembly) and roller-top (for transfer) at the same facility, SRE Material Handling Equipment Pvt. Ltd. can supply mixed orders from a single purchase.
Vadodara ke production line ke liye Scissor Lift Table With Roller ki price kya hai aur roller ka material kya hoga?
Vadodara ke production lines ke liye SRE Scissor Lift Table With Roller ki price Rs. 26,000 (taxes extra) hai — standard model mein 50 mm diameter steel rollers, 120 kg per roller rated, 75 mm centre spacing. PU-coated rollers sensitive products (painted parts, glass, pharma cartons) ke liye available hain custom order pe. Custom roller size, spacing, aur platform size bhi specify kar sakte hain. SRE Material Handling Equipment Pvt. Ltd. — ISO 9001:2015 certified — lead time 12–15 working days hai roller-top models ke liye.
Gujarat ke FMCG ya pharma packaging line mein Roller Top Scissor Lift Table kaise install karte hain aur koi civil work chahiye?
Gujarat ke FMCG aur pharma packaging lines mein roller-top scissor lift table freestanding hai — koi civil work ya floor fixing nahi chahiye standard applications mein. Unit factory floor pe directly rakhte hain conveyor infeed ke saas. Agar floor pe anchor karna ho (vibration-heavy environment ke liye), floor bolt holes available hain base frame mein. SRE Material Handling Equipment Pvt. Ltd. installation guide provide karta hai aur bulk orders ke liye on-site installation support bhi arrange kar sakta hai Ahmedabad aur Vadodara nearby locations ke liye.
Pune ya Bangalore ke conveyor-fed assembly line ke liye Scissor Lift Table With Roller ki delivery kitne time mein milegi?
Pune aur Bangalore ke conveyor-fed assembly lines ke liye standard Scissor Lift Table With Roller delivery 12–15 working days mein hoti hai. Custom roller specs (PU coating, different diameter, custom spacing) ke liye 18–22 working days. SRE Material Handling Equipment Pvt. Ltd. — MSME registered, Make in India manufacturer — GST invoice, quality test report, aur freight coordination saath mein provide karta hai. Bulk orders ke liye priority production slot aur consolidated freight available hai.
