350 kg 3 Meter H (All Size Available)
Rs. 180000
(Taxes to be paid extra)
Brand: SRE
SKU: SRE 125
Min Order Qty: 1
What Is a Semi Battery Drum Lifter & Tilter and How Does It Work in Chemical and Pharma Dispensing Facilities Across Gujarat?
A semi battery drum lifter and tilter combines three functions in a single machine: drum clamping (securing the drum in a cradle or clamp), electric lift (raising the clamped drum to the required dispensing height using a battery-powered hydraulic unit), and drum tilt/rotation (pivoting the drum on a horizontal axis to pour or dispense contents). In the SRE 125, the lift is battery-powered — controlled by push-button pendant — while the machine’s base travels manually (pushed by the operator on castor wheels). This semi-battery configuration is optimal for dispensing operations where the drum is brought to the equipment, lifted and tilted in a fixed position — making powered travel an unnecessary cost addition for the majority of dispensing applications in Vatva, Kathwada, Kalol, Gandhinagar, Mahesana, Bhavnagar, Kutch, and Himmatnagar facilities.Semi Battery Drum Lifter Tilter (SRE 125) vs. Manual Drum Tilter vs. Fully Battery Drum Lifter — Choosing the Right Configuration
| Feature | Manual Drum Tilter | Semi Battery Drum Lifter Tilter (SRE 125) | Fully Battery Drum Lifter Tilter |
|---|---|---|---|
| Lift Height | Floor level only (tilt on floor) | Up to 3 Metres (electric lift) | Up to 3+ metres |
| Travel | Manual push | Manual push (semi battery) | Battery-powered drive |
| Tilt Range | 0–90° | 0–360° (full rotation) | 0–360° |
| Capacity | Up to 200 kg | 350 kg | 350–500 kg |
| Best Application | Floor-level dispensing into low-height vessels | Raised-vessel dispensing, IBC filling, reactor feeding | High-frequency, long-distance dispensing circuits |
| Price (India) | ₹25,000–60,000 | ₹1,80,000 | ₹2.5–4 lakh |
Need a drum lifter and tilter for your dispensing or blending operation?📋 Get a Free Quote Now
📞 Call: +91 97247 22404
Industrial Applications of the SRE 125 Semi Battery Drum Lifter & Tilter Across Vadodara, Hyderabad, Pune, and Bangalore
The SRE 125 semi battery drum lifter and tilter is specified wherever drums must be lifted above floor level and tilted to dispense into reactors, IBCs, mixers, or storage vessels — replacing two-person manual operations that carry serious chemical exposure, spill, and musculoskeletal injury risks. Here are the verified application scenarios from client facilities across Vatva, Kathwada, Kalol, Gandhinagar, Mahesana, Bhavnagar, Kutch, Himmatnagar, and Chattral:- Pharmaceutical API Dispensing — Lifting solvent drums to dispensing platform height and tilting into weigh vessel or reactor in API manufacturing facilities in Hyderabad, Bangalore, and Ahmedabad — where GMP dispensing requires precise, controlled pour and SS 316L contact parts documentation.
- Chemical Plant Reactor Feeding — Lifting and tilting raw material chemical drums into reactor manholes at 1.5–3 metre height in chemical plants in Vadodara, Vatva, and Ankleshwar — eliminating two-person manual drum handling at height in hazardous process areas.
- Paint and Resin Manufacturing — Loading pigment, resin, and additive drums into elevated mixing vessels in paint production lines in Jaipur, Udaipur, and Indore — where tilting accuracy directly affects batch consistency.
- Food-Grade Liquid Dispensing — Emptying flavouring concentrate, edible oil, and liquid glucose drums into elevated mixing tanks in food and beverage plants in Gujarat and Maharashtra — SS 304 or 316L contact surface option available for FSSAI compliance.
- Lubricant Blending Units — Lifting and tilting base oil and additive drums into blending kettles at lubricant manufacturing and blending plants in Pune, Gurugram, and Chennai.
- Adhesive and Sealant Manufacturers — Feeding adhesive raw material drums into heated mixing vessels at height in adhesive manufacturing plants in Gujarat and Rajasthan — where viscous materials require full drum inversion for complete emptying.
- Agrochemical Dispensing — Emptying pesticide and herbicide drums into formulation tanks at height in agrochemical manufacturing plants in Kutch, Gandhinagar, and Mahesana.
- Ink and Pigment Production — Lifting and tilting pigment drums into dispersion mills and mixing tanks in ink manufacturing plants across Gujarat, Maharashtra, and Noida.
- Dairy and Edible Fat Processing — Tilting and emptying fat and liquid dairy ingredient drums into processing vessels at elevated positions in dairy and edible fat plants in Gujarat and Rajasthan.
- Industrial Cleaning and Solvent Plants — Dispensing solvent and cleaning chemical drums into mixing or dosing stations in industrial chemical facilities across Gujarat, Maharashtra, and Karnataka.
“A pharmaceutical company in Hyderabad had a dispensing operation where two operators were manually tilting 180-kg solvent drums over a weigh vessel at 1.8 metres — a serious EHS risk at every batch. After deploying three SRE 125 semi battery drum lifter tilters, dispensing became a single-operator operation with zero spill incidents and a measurable reduction in operator chemical exposure events in the first quarter.”
— EHS Solutions Partner, SRE Material Handling Equipment Pvt. Ltd., Ahmedabad
Key Technical Features of the SRE 125 Semi Battery Drum Lifter & Tilter for Procurement Managers in Noida, Faridabad, and Gurugram
- Rated Capacity: 350 kg — Covers full 210-litre steel drums of most chemicals (water-based: 220 kg; solvent-based: 180 kg; high-density liquid: up to 350 kg). Overload protection via hydraulic relief valve.
- Maximum Lift Height: 3 Metres — Sufficient to reach reactor manholes, IBC top fills, and mixing vessel inlets at 2–2.8 m height across the majority of process plant configurations. Custom heights up to 4 m available.
- Lift System: Semi Battery (Electric Lift, Manual Travel) — 24V DC electric-hydraulic lift controlled by push-button pendant; manual push travel on 4 castor wheels (2 fixed, 2 swivel with brakes). Battery: 24V / 80Ah maintenance-free.
- Tilt/Rotation: 0–360°, Worm Gear Controlled — Worm gear reducer provides stepless tilt from 0° (drum upright) to 180° (full inversion) to 360° (drum returned upright). Self-locking gear holds drum at any tilt angle without operator effort — critical for controlled-pour operations.
- Drum Cradle: Rubber-Lined MS Steel Hoops — Two rubber-lined grip hoops sized for 210-litre drums (580–600 mm body diameter, 559 mm standard body). Rubber lining prevents metal-to-drum contact abrasion and provides grip during tilt. SS 304 or 316L cradle option for pharma and food-grade.
- Mast Construction: MS Steel, Single Post, Powder-Coated — Single-post mast with chain-driven or belt-driven carriage. Mast designed for indoor use; powder-coated for corrosion resistance. SS mast option for corrosive environments.
- Castor Wheels: 200 mm Dia, Nylon, Foot-Brake Swivel Castors — Two swivel castors (front) with foot-actuated brake; two fixed castors (rear) for straight-line travel. Load rating: 250 kg per castor.
- Safety: Mechanical Safety Latch, Emergency Lower — Mechanical safety latch prevents carriage from descending in case of hydraulic system failure. Emergency manual lower valve allows safe drum descent without battery power.
- Machine Weight: Approx. 220 kg — Portable between dispensing stations by one operator on smooth industrial floors.
Why Pharma Companies and Chemical Manufacturers in Jaipur, Chennai, and Bangalore Choose SRE Material Handling Equipment Pvt. Ltd. for Drum Lifter Tilter Supply
The semi battery drum lifter tilter is a precision piece of process equipment — not just a material handling tool. Buyers in regulated industries (pharma, food, specialty chemicals) in Jaipur, Chennai, and Bangalore require documentation depth beyond what generic suppliers provide: material certificates for stainless contact parts, load-test records, and quality management system traceability. SRE Material Handling Equipment Pvt. Ltd., founded in 2011 and ISO 9001:2015 certified, provides all three as standard for regulated-sector orders. The SRE 125 at Rs. 1,80,000 is priced 35–50% below imported drum lifter tilters from European or Taiwanese manufacturers while meeting equivalent functional specifications. For bulk procurement — 3 to 10 units for a large pharma or chemical manufacturing campus in Gujarat, Maharashtra, or Telangana — SRE Material Handling Equipment Pvt. Ltd. offers dedicated production scheduling, consolidated freight, and a single warranty management point. Drum handling safety reference: OSHA manual handling guidelines. Indian GMP equipment standards: BIS industrial equipment standards.Make drum dispensing a safe, single-operator operation.🏭 Get a Quote for Bulk Orders
