Dual Mast Goods Lift

1 ton x 12 Feet (All Size Available)

Rs. 200000

(Taxes to be paid extra)

Brand: SRE

Min Order Qty: 1

Factory owners and warehouse operators across Ahmedabad, Vatva, and Kathwada GIDC regularly run into the same infrastructure problem: the moment a second floor, mezzanine, or elevated production deck is added to a facility, the only way to move heavy goods vertically is either a passenger lift (not rated for cargo), a forklift ramp (requires floor space, access clearance, and a licensed driver), or human manual carry — all three of which introduce either cost, safety exposure, or throughput bottlenecks. The Dual Mast Goods Lift from SRE Material Handling Equipment Pvt. Ltd. addresses this precisely: a 1 ton vertical freight elevator with a 12-foot (3.66 metre) lift height, hydraulic-electric drive, and a compact dual mast structure that fits inside existing factory and warehouse column grids without civil modification — giving multi-floor operations in Gujarat, Maharashtra, and across India a dependable cargo elevator that integrates in days, not months.

What Is a Dual Mast Goods Lift and Why It Outperforms Single Mast Designs for Factory Owners in Ahmedabad and Gujarat

Plant managers in Ahmedabad‘s Vatva and Kathwada industrial zones often ask why a dual mast goods lift is specified over a single mast design for their mezzanine floor cargo transfer requirements. The structural reason is straightforward: a single mast creates a cantilevered load path — the platform weight plus cargo weight applies a bending moment at the single mast column, requiring a much heavier base frame and more robust anchor bolts to prevent tipping under off-center loads. A dual mast configuration places two vertical IS:2062 Grade B structural steel channels on either side of the platform, creating a balanced load path with the cargo distributed symmetrically across both masts. The result is a stiffer, more stable platform at rated 1,000 kg capacity with less structural deflection under dynamic loading — critical for operations in Gujarat where the goods being lifted include engine assemblies, reel stock, and chemical drums that create impact loads during loading.

Hydraulic vs. Chain-Drive Goods Lift — What Procurement Managers in Pune and Noida Need to Evaluate

When purchase heads in Pune and Noida compare goods lift drive systems, the critical differentiator is maintenance frequency. A chain-drive goods lift uses a mechanical chain-and-sprocket system that requires lubrication every 300–500 operating hours, periodic chain tension adjustment, and sprocket replacement typically every 18–24 months in high-cycle applications. SRE’s dual mast goods lift uses a hydraulic power pack with a 220-bar single-acting cylinder — the hydraulic oil provides inherent lubrication to all cylinder surfaces, with oil change intervals of 2,000 operating hours under normal conditions. The hydraulic system also enables cushioned stop at the top and bottom of travel, preventing platform bounce and cargo shift that chain-drive systems experience at speed, particularly important for fragile cargo handling at Pune‘s pharma distribution facilities and Noida‘s electronics component warehouses.

Goods Lift vs. Passenger Lift vs. Forklift Ramp — The Right Vertical Transfer Choice for Maharashtra and Rajasthan Facilities

A facility manager in Jaipur or Bhopal evaluating vertical material transfer options needs a clear cost-performance framework. A passenger elevator in India requires Lift Inspector certification, annual mandatory inspection, and structural shaft construction — typically ₹8–15 lakh for installation including civil works, and 3–6 months of lead time. A forklift ramp needs 8–12 metres of floor run to achieve a 3.5 metre height change, consumes 80–120 sq. ft. of floor area, and requires a forklift driver and truck every time material is moved. A dual mast goods lift at ₹2,00,000 installs on an existing floor slab in 3–5 days, occupies a platform footprint of approximately 1,200 × 1,500 mm, and one operator can send a 1,000 kg pallet between floors with a push-button controller. For Rajasthan and Maharashtra factory owners looking to maximize mezzanine floor utilization without committing to elevator shaft civil works, the goods lift is the operationally and financially superior solution.

Industrial Applications of Dual Mast Goods Lift in Factories and Warehouses Across Ahmedabad, Bangalore, Chennai, and Noida

The dual mast goods lift at 1 ton capacity and 12 feet (3.66 m) lift height is the standard specification for mezzanine floor cargo transfer in the majority of Indian factory and warehouse applications — where floor-to-first-floor height is typically 10 to 14 feet. Every industry that uses multi-level floor space for production, storage, or dispatch benefits from a freight elevator at this size class. The following are the confirmed, active-deployment applications where SRE’s dual mast goods lift is operating on real production and logistics floors across Gujarat, Maharashtra, Karnataka, Rajasthan, and the NCR region:

• Mezzanine Floor Pallet and Cargo Transfer in Warehouses — Moving full pallets (up to 1,000 kg) between ground floor receiving areas and mezzanine storage decks in distribution centers at Ahmedabad, Vadodara, Pune, and Gurugram — replacing manual carry and eliminating the forklift ramp access requirement.
• Multi-Floor Production Flow in Manufacturing Plants — Transferring semi-finished assemblies, raw material batches, and finished goods between production floors in factories at Bangalore‘s Peenya and Chennai‘s Ambattur industrial estates, where floor-to-floor material flow is a daily production requirement.
• Pharmaceutical Raw Material and Finished Goods Movement — Moving carton pallets of API bulk, packaging materials, and finished pharmaceutical goods between storage and dispatch floors in GMP-classified environments at Ahmedabad‘s pharma GIDC and Vadodara‘s pharmaceutical manufacturing clusters, where the electric-hydraulic drive system produces zero exhaust contamination.
• Automotive Parts and Sub-Assembly Transfer — Lifting engine components, gearbox assemblies, pressed body panels, and tooling between machining and assembly floors at Pune‘s Chakan belt, Bangalore‘s KIADB zone, and Chennai‘s automotive corridor, where the cushioned stop system prevents part damage on arrival.
• Retail and Hypermarket Stock Transfer — Moving carton stock from ground-floor receiving docks to mezzanine stockrooms in large-format retail outlets at Hyderabad, Noida, Gurugram, and Faridabad, where a goods lift eliminates dependence on a dedicated stockroom operator with a pallet trolley and ramp every shift.
• FMCG Distribution Center Inbound-Outbound Operations — Handling inbound receipt pallets from trucks at ground level and transferring them to elevated pick zones at Bhavnagar, Ghandhidham, and Mahesana FMCG distribution hubs, where lift cycle speed directly impacts dock-to-shelf time.
• Printing and Packaging Industry Paper Reel Transfer — Moving heavy paper reels and corrugated board pallet loads (typically 600–900 kg each) between ground-floor reel storage and elevated printing press floor areas in packaging facilities across Indore, Bhopal, and Rohtak.
• Cold Chain and Refrigerated Warehouse Vertical Transfer — Moving chilled and frozen goods pallets between ground-level cold dock and elevated frozen storage decks in cold storage facilities at Ahmedabad, Pune, and Chennai agri-logistics zones, where the sealed hydraulic system is unaffected by low-temperature operating environments (down to -10°C).

Model Configuration	Rated Capacity	Lift Height	Platform Size (mm)	Power Supply	Best Application
SRE DML-1T-12F (Standard)	1,000 kg	12 ft (3.66 m)	1200 × 1500	3-Phase, 415V, 50Hz	Factory Mezzanine, Warehouse
SRE DML-1T-16F	1,000 kg	16 ft (4.88 m)	1200 × 1500	3-Phase, 415V, 50Hz	High Mezzanine, Two-Level Factory
SRE DML-2T-12F	2,000 kg	12 ft (3.66 m)	1500 × 2000	3-Phase, 415V, 50Hz	Heavy Industry, Automotive Plants
SRE DML-500-12F	500 kg	12 ft (3.66 m)	1000 × 1200	Single-Phase, 230V, 50Hz	Small Warehouse, Retail Stockroom
SRE DML-3T-20F	3,000 kg	20 ft (6.10 m)	2000 × 2500	3-Phase, 415V, 50Hz	Heavy Engineering, Port Logistics

Key Features and Technical Specifications of SRE Dual Mast Goods Lift for Procurement Heads in Ahmedabad, Hyderabad, and Faridabad

A purchase head in Hyderabad or Faridabad evaluating a dual mast goods lift for a ₹2 lakh capital procurement needs to look beyond the rated capacity and lift height to understand what structural and safety design decisions have been made inside the machine. SRE Material Handling Equipment Pvt. Ltd.‘s dual mast goods lift uses ISMC 150 channel sections (IS:2062 Grade B) for both mast uprights, with inter-mast cross-bracing at every 1,000 mm of height using 25 mm × 6 mm MS flat bar gussets welded to IS:1323 standards. The platform frame is fabricated from 50 × 50 × 5 mm MS angle sections with a 6 mm MS chequered plate deck, rated to uniformly distributed load with a platform deflection not exceeding L/300 at rated capacity. Rated lift speed is 0.05 m/s to 0.08 m/s — slow and controlled, as required for safe cargo handling on production floors at Ahmedabad, Vadodara, and Bangalore manufacturing facilities.

Safety systems are the non-negotiable checklist for EHS officers approving goods lift installation at facilities in Indore, Bhopal, and Ambala. The SRE dual mast goods lift incorporates four independent safety mechanisms: (1) Upper and lower limit switches (electro-mechanical, NO/NC dual contact) that cut hydraulic pump power at precise travel limits; (2) Slack cable/chain safety device (where applicable to model) that engages the platform lock if the load-side cable loses tension; (3) Safety gates with mechanical interlock at both loading and receiving floors — the platform does not move unless both gates are closed and latched; (4) Manual emergency lowering valve accessible from ground level — allowing controlled platform descent during a power outage without requiring any tools or electrician intervention. This four-layer safety architecture directly satisfies the incoming inspection requirements of ISO 9001-certified facilities in Rohtak, Gurugram, Chattral, and Himmatnagar.

Why Plant Managers and Logistics Heads from Ahmedabad to Chennai Choose SRE Material Handling Equipment Pvt. Ltd. for Goods Lift Procurement

When a facility head in Chennai‘s Ambattur industrial area or Hyderabad‘s Medchal manufacturing zone is commissioning a dual mast goods lift for a new mezzanine installation, the procurement conversation is not only about price — it is about civil interface, installation support, and what happens if a hydraulic seal fails at 11 PM on a production night. SRE Material Handling Equipment Pvt. Ltd., an ISO 9001:2015 certified and MSME-registered manufacturer founded in 2011 in Ahmedabad, provides full installation drawings, foundation load data, and a civil interface specification with every goods lift order — so the buyer’s structural engineer can sign off on the floor slab adequacy before delivery. Every unit is assembled, load-tested at 125% of rated capacity, and hydraulic-pressure-tested at 1.5× working pressure before dispatch.

For buyers placing multi-unit orders from Noida, Gurugram, Faridabad, and Rohtak logistics clusters who are equipping multiple warehouse levels simultaneously, SRE Material Handling Equipment Pvt. Ltd. provides a scheduled delivery program — confirming dispatch date, transport route, and expected site arrival for each unit in a batch. Spare parts — hydraulic seals, limit switches, control contactors, safety gate catches — are stocked at the Ahmedabad facility and dispatched within 48 hours to anywhere in Gujarat, Maharashtra, Rajasthan, Karnataka, Tamil Nadu, Telangana, Haryana, Uttar Pradesh. For facilities in Bhavnagar, Kutch, Kalol, Mahesana, and Ghandhidham, the same-state logistics advantage means most standard spares arrive next-day — keeping a hydraulic seal failure from becoming a multi-day production shutdown.

Installation, Maintenance & After-Sales Support for Dual Mast Goods Lift Across Gujarat, Rajasthan, and Maharashtra

A plant manager in Jaipur or Udaipur placing a first order for a dual mast goods lift wants to know three things before signing the purchase order: how long does installation take, who does the commissioning, and what is the first maintenance interval? For the standard SRE 1-ton × 12-foot dual mast goods lift, installation by the buyer’s civil and electrical team using SRE’s provided drawings takes 3 to 5 working days for the structural assembly and electrical connection. SRE’s commissioning engineer visits the site after installation to set limit switches, test safety gate interlocks, perform a loaded travel test at rated capacity, and hand over an operating manual with maintenance schedule. The first hydraulic oil service is recommended at 500 operating hours, subsequent changes at 2,000 hours — using ISO VG 46 hydraulic oil available from any industrial lubricant supplier in Jaipur, Udaipur, Bhopal, or Indore.

For a complete multi-floor vertical and horizontal material flow solution, SRE Material Handling Equipment Pvt. Ltd. offers the Electric Stacker for floor-level pallet handling adjacent to the goods lift receiving point, the Pallet Truck for ground-level dock-to-lift transfer, and the Dock Leveler for bridging the height gap between truck bed and warehouse floor at the inbound loading bay. Deepen your technical understanding through our guide on safe elevated operations, our article on smart material handling output, and our insight on lifting faster and working safer.

The design, testing, and safety requirements for industrial goods lifts and freight elevators are governed by internationally and nationally recognized standards. ISO safety standards for lifts and elevating work platforms at ISO.org define rated load, stability, and safety device requirements applicable to industrial goods lifts. OSHA’s Elevated Work Platform and Lift safety guidelines outline operator protection, gate interlock, and overload prevention requirements consistent with best practices for industrial material lifts in Indian factories. Buyers requiring Indian standards should reference Bureau of Indian Standards (BIS) for applicable IS codes governing industrial lift equipment manufacturing and safety compliance in India.
